Home Products MAXUS CUT 100M
MAXUS CUT 100M
Product image thumbnail 1
Product image thumbnail 2
Product image thumbnail 3
Product image thumbnail 4
Plasma Cutters

MAXUS CUT 100M

Get smooth and accurate metal cuts with MAXUS CUT 100M, designed for efficient operation across stainless steel and mild steel applications.

Technical Specifications

Input Voltage 415V 3ph Input
Current Range 30-100A Range
System Feature 31.2 KG Weight
Duty Cycle 100% Duty Cycle

Machine Specifications

Input Voltage 415V 3ph 50/60Hz
Input Current 26A
Open Circuit Voltage 312V
Output Current Range 30–100A
Duty Cycle (40°C) 100%@100A
Efficiency ≥88.5(%)
Power Factor 0.88 cosφ
Insulation Class H
Protection Class P21S
Dimensions (L×W×H) 547×262×501 mm
Weight 31.2 KG
Cutting Thickness (MM) 1–30

Package Contents

  • 8M Torch
  • 16mm² × 3m Ground Cable
  • Regulator

Key Features

  • Constant Current (CC) output
  • High-frequency arc ignition
  • Built-in post-flow function
  • Easy arc starting
  • Smooth cutting performance
  • Inverter-based technology

Customer Benefits

  • Delivers clean and precise metal cuts.
  • Ensures smooth cutting with easy arc ignition.
  • Reduces post-cut finishing time.
  • Performs efficiently on stainless steel and mild steel.
  • Ideal for fabrication and maintenance work.
  • 2 year warranty included
