MAXUS CUT 120M
Product image thumbnail 1
Product image thumbnail 2
Product image thumbnail 3
Product image thumbnail 4
Plasma Cutters

MAXUS CUT 120M

Get consistent results on demanding metal cutting jobs with MAXUS CUT 120M, built for efficiency, stability, and reliable industrial performance.

Technical Specifications

Input Voltage 415V 3ph Input
Current Range 30-120A Range
System Feature 30 KG Weight
Current Range Cutting Cap up to 40mm

Machine Specifications

Input Voltage 3~AC415V±10% / 50/60
Input Current 30A
Open Circuit Voltage 324V
Output Current Range 30–120A
Duty Cycle (40°C) 60%
Efficiency >88.5(%)
Power Factor 0.88 cosφ
Insulation Class H
Protection Class IP21S
Dimensions (L×W×H) 547×262×501 mm
Weight 30 KG
Cutting Thickness (MM) 1–40

Package Contents

  • 8M Torch
  • 16mm² × 3m Ground Cable
  • Regulator

Key Features

  • Constant Current (CC) output
  • High-frequency plasma ignition
  • Integrated post-flow function
  • Stable cutting performance
  • Easy arc initiation
  • Reliable inverter technology

Customer Benefits

  • Cuts thicker materials with ease.
  • Produces clean, smooth cutting edges.
  • Increases productivity with stable operation.
  • Suitable for diverse industrial applications.
  • Delivers dependable and long-term performance.
  • 2 year Warranty included
