MAXUS MIG 400 PRO
Product image thumbnail 1
Product image thumbnail 2
Product image thumbnail 3
Product image thumbnail 4
MIG Welders

MAXUS MIG 400 PRO

Improve welding efficiency with MAXUS MIG 400 PRO, engineered to provide stable performance and consistent results across challenging applications.

Technical Specifications

Input Voltage 3P AC415V Input
Current Range 40-400A Range
System Feature 32.8 KG Weight
System Feature Intelligent Parameters

Machine Specifications

Input Power 3~AC415V±10% / 50/60
Rated Input Current (A) 21.5
No-load Voltage (V) 66
Output Voltage Adjustment (V) 12–40
Output Current Adjustment (A) 40–400
Duty Cycle (40°C) 60%
Efficiency (%) >86
Insulation Class H
Protection Class P21S
Dimensions (MM) 557×280×540
Weight 32.8 KG

Package Contents

  • 5m MIG Gun (euro)
  • 2m, 35mm² – Ground Cable
  • Wire feeder (dual drive)
  • 10m, 35mm² – Welding cable
  • gas hose
  • control cable

Key Features

  • Advanced digital chip control
  • Dual IGBT power modules
  • Precise arc voltage feedback
  • Built-in expert parameters
  • Stable welding output
  • Industrial-grade construction

Customer Benefits

  • Improves welding precision and productivity.
  • Delivers consistent weld quality.
  • Simplifies parameter selection.
  • Supports long-duration industrial welding.
  • Enhances overall operational efficiency.
  • 2-Year Warranty Included
